This series of machines can be used to test a variety of materials, finished products, tensile structures, compression, tear, peel, shear, bending, bending strength and other physical properties. This series is easy to operate, high precision, wide speed range, high sampling frequency, the optional multiple sensors and fixture, make a testing machine to complete the the multiple testing machine function. At the same time according to GB, ISO, JIS, ASTM, DIN and provide users with a variety of standard tests and data processing. This series of tests is widely used in wire and cable, rubber plastic, paper packaging, wire and cable, packaging, printing, textile and leather, clothing footwear and other industries, quality control, physical test equipment. The ideal test equipment for scientific research institutes, universities, industrial enterprises, technical supervision, inspection arbitration department.
First, to meet the standard:
"GB/T16491-1996 Electronic universal testing machine
Industry:
Measurement quality control; rubber plastic; iron and steel metallurgy; machinery manufacturing; electronic appliances; automobile production; textile and chemical fiber; wire and cable; packaging materials and food; instrumentation; medical devices; civilian nuclear energy; civil aviation; colleges and universities; research laboratories; inspection arbitration, technical supervision departments; ceramic building materials; petrochemicals; other industry.
Third, the structural principle:
This machine adopts mechatronics design, mainly by the force sensor, transmitter, microprocessor, load drive mechanism, computer and color inkjet printer institutions into.
Fourth, the function and role:
The computer monitors the entire test process, curve, microcomputer automatic transmission test set and test information. Users according to their own requirements to modify the test report, the output of standard reports. Superimposed on the curve of the group test can accurately grasp the quality control parameters. Multi-way data query capabilities, and allows managers to clearly grasp the trend of the development of quality control. Specially designed software features, it enables test the quantitative grasp the state parameters of the key points in the application process of the test material, and accurate process adjustments and production control.
Fifth, the software features:
1.Test standard modular functions: to provide the user to set the desired application testing standards set covers GB, ASTM, DIN, JIS, BS ... etc.. Testing standards.
2 test product: Provides the user to set all the test data, the input data is permanently reuse. And self upgrading the formula to improve the test data fit.
3.Dual statements edit: completely open user edit statements, choose their own preferred report format for testing (the test program new built-in the EXCEL report editing function extends past pattern of single professional report)
4.length, power units, the number of bits dynamic exchange forces units Kgf, N, KN, gf, lb, deformation units mm, cm, inch.
5.The scale of graph is automatically optimized Auto Scale, allows graphics best scale. Dynamic switching and instant graphical test. Load - displacement, load - time, displacement - time, stress - strain extension load -2 points chart, as well as multiple curve comparison.
6.The test results can output data in the form EXCEL format.
7.The end of the test can be automatically archived, manual archiving, testing is completed automatically calculating the maximum force on the lower yield strength, hysteresis loop method, successive approximation, the non-proportional extension strength, tensile strength, compressive strength, at any point given elongation The intensity at any point given load extension, elastic modulus, elongation, peel range maximum, minimum, average, net energy, exhumation of energy, total energy, flexural modulus, breakpoints displacement x% load breakpoints load X % displacement, and so on. Data Backup: The test data can be saved in any hard disk partition.
8 languages randomly switching: simplified Chinese, traditional Chinese, English.
